Class 1000
Alloys Temper Tensile strength
Rm (Mpa)
Yield strength
Min. Rp0,2 (Mpa)
Elongation min.
%**
Electrical conductivity
(MS/m)
1050A O 65-95 20 22 34,5
H12 85-125 65 4
H14 105-145 85 3
H16 120-160 100 2
H18 140 Min 120 2
H19 150 Min 130 1
1070A O 60-90 15 25 35,4
1200 O 75-105 25 21
H12 95-135 75 4
H14 115-155 95 3
H16 130-170 115 2
H18 150 Min 130 2
H19 160 Min 140 1
*1350A O 65-105 20 22 35,4
*1370A O 65-105 20 22 35,8

* Alloys for electrotechincal applications
** Elongation related to thicknesses 0.5 – 1.5 measured on piece of 50 mm strength

CLASS 3000
Alloys Temper Tensile strength
Rm (Mpa)
Yield strength
Min. Rp0,2 (Mpa)
Elongation min.
%**
3003 O 95-135 35 17
H22 120-160 80 4
H24 145-185 115 4
H26 170-210 140 3
H18 190 Min 170 2
H19 210 Min 180 2
3103 O 90-130 35 19
H22 115-155 75 7
H24 140-180 110 4
H26 160-200 135 3
H18 185 Min 165 2
H19 200 Min 175 2
3005 O 115-165 45 14
H22 145-195 110 5
H24 170-215 130 4
H26 195-240 160 3
H18 220 Min 200 2
3105 O 100-155 40 15
H22 130-180 105 6
H24 150-200 120 4
H26 175-225 150 3
H18 195 Min 180 1

** Elongation related to thicknesses 0.5 – 1.5 measured on piece of 50 mm strength

CLASS 5000
Alloys Temper Tensile strength
Rm (Mpa)
Yield strength
Min. Rp0,2 (Mpa)
Elongation min.
%**
5005 O 100-145 35 19
H22/H32 125-165 80 5
H24/H34 145-185 110 4
H26/H36 165-205 135 3
H18 185 Min 165 2
H19 205 Min 185 2
5049 O 190-240 80 14
H22/H32 220-270 130 8
H24/H34 240-280 160 6
H26/H36 265-305 190 4
H18 290 Min 250 2
5052 O 170-215 65 14
H22/H32 210-260 130 6
H24/H34 230-280 150 5
H26/H36 250-300 180 4
H18 270 Min 240 2
5083 O 275-350 125 12
H22/H32 305-380 215 6
H24/H34 340-400 250 5
  H26/H36 360-420 280 3
5086 O 240-310 100 12
H22/H32 275-335 185 6
H24/H34 300-360 220 5
  H26/H36 325-385 250 3
  H18 345Min 290 1
5754 O 190-240 80 14
H22/H32 220-270 130 8
H24/H34 220-270 130 8
H26/H36 240-280 190 3
H18 240-280 160 6
5182 O 255-315 110 12

** Elongation related to thicknesses 0.5 – 1.5 measured on piece of 50 mm strength

CHEMICAL COMPOSITION (EN 573/3)
Alloy
nomination
Si Fe Cu Mn Mg Cr Zn Ti Ga Observations Others Aluminium min.
Numerical Chemical symbols Each Total
EN AW-1080A EN AW-AI 99,8(A) 0,15 0,15 0,03 0,02 0,02 – 0,06 0,02 0,03 – 0,02 – 99,8
EN AW-1070A EN AW-Al 99,7 0,20 0,25 0,03 0,03 0,03 – 0,07 0,03 – – 0,03 – 99,7
EN AW-1370 EN AW-Al 99,7 0,10 0,25 0,02 0,01 0,02 0,01 0,04 – 0,03 0,02B ; 0,02V + Ti 0,02 0,1 99,7
EN AW-1050A EN AW-AI 99,5 0,25 0,40 0,05 0,05 0,05 – 0,07 0,05 – – 0,03 – 99,5
EN AW-1350A EN AW-Al 99,5 (A) 0,25 0,40 0,02 – 0,05 – 0,05 – – 0,03Cr+Mn+Ti+V 0,03 – 99,5
EN AW-1100 EN AW-Al 99,0Cu 0,95 Si+Fe 0,05-0,20 0,05 – – 0,1 – – – 0,05 0,15 99
EN AW-1200 EN AW-AI 99,0 1,00 Si+Fe 0,05 0,05 – – 0,1 0,05 – – 0,05 0,15 99
EN AW-1200A EN AW-AI 99,0A 1,00 Si+Fe 0,1 0,3 0,3 0,1 0,1 – – – 0,05 0,15 99
EN AW-3003 EN AW-AI Mn1Cu 0,6 0,7 0,05-0,20 1,0-1,5 – – 0,1   – – 0,05 0,15 *
EN AW-3103 EN AW-AI Mn1 0,50 0,7 0,1 0,9-1,5 0,3 0,1 0,2   – 0,10Zr+Ti 0,05 0,15 *
EN AW-3005 EN AW-AI Mn1Mg0,5 0,6 0,7 0,3 1,0-1,5 0,20-0,6 0,1 0,25 0,1 – – 0,05 0,15 *
EN AW-3105 EN AW-AI Mn0,5Mg0,5 0,6 0,7 0,3 0,30-0,8 0,20-0,8 0,2 0,4 0,1 – – 0,05 0,15 *
EN AW-5005A EN AW-AI Mg1(C) 0,30 0,45 0,05 0,15 0,7-1,1 0,1 0,2   – – 0,05 0,15 *
EN AW-5049 EN AW-AI Mg2Mn0,8 0,40 0,50 0,1 0,50-1,1 1,6-2,5 0,3 0,2 0,1 – – 0,05 0,15 *
EN AW-5251 EN AW-AI Mg2 0,40 0,50 0,15 0,10-0,50 1,7-2,4 0,15 0,15 0,15 – – 0,05 0,15 *
EN AW-5052 EN AW-AI Mg2,5 0,25 0,40 0,1 0,1 2,2-2,8 0,15-0,35 0,1   – – 0,05 0,15 *
EN AW-5754 ENAW-AI Mg3 0,40 0,40 0,1 0,5 2,6-3,6 0,3 0,2 0,15 – 0,10-0,6 Mn+Cr 0,05 0,15 *
EN AW-5083 EN AW-AI Mg4,5Mn0,7 0,40 0,40 0,1 0,40-1,0 4,0-4,9 0,05-0,25 0,25 0,15 – – 0,05 0,15 *
EN AW-5086 EN AW-AI Mg4 0,40 0,50 0,1 0,20-0,7 3,5-4,5 0,05-0,25 0,25 0,15 – – 0,05 0,15 *
EN AW-5182 EN AW-Al Mg4,5Mn0,4 0,20 0,35 0,15 0,20-0,50 4,0-5,0 0,1 0,25 0,1 – – 0,05 0,15 *

* Remaining

CHEMICAL COMPOSITION AND MECHANICAL PROPERTIES
Alloy Mechanical properties (EN 1592-2) Chemical composition (EN 573-3)
Temper Rm N/mm2 Rp 0,2 N/mm2 A5 % Si Fe Cu Mn Mg Cr Zn Ti Other
EN
AW-3004
EN AW-AL
Mn1 Mg1
H125
H145
H165
H185
190
220
240
250
145
180
200
220
8
6
4
3
≤ 0,30 ≤ 0,70 ≤ 0,25 1,00
÷
1,50
0,8
÷
1,30
≤ 0,25
EN
AW-3005
EN AW-AL
Mn1 Mg0,5
H145
H165
H185
200
210
220
175
185
195
7
5
4
≤ 0,60 ≤ 0,70 ≤ 0,30 1,00
÷
1,50
0,20
÷
0,60
≤ 0,10 ≤ 0,25 ≤ 0,10
EN
AW-5049
EN AW-AL
Mg2 Mn0,8
H125
H145
H165
H185
220
235
250
270
170
200
230
250
10
7
5
3
≤ 0,40 ≤ 0,50 ≤ 0,10 0,50
÷
1,10
1,60
÷
2,50
≤ 0,30 ≤ 0,20 ≤ 0,10
EN
AW-5251
EN AW-AL
Mg2
H125
H145
H165
210
230
245
160
190
210
8
6
5
≤ 0,40 ≤ 0,50 ≤ 0,15 0,10
÷
0,50
1,70
÷
2,40
≤ 0,15 ≤ 0,15 ≤ 0,15
EN
AW-5754
EN AW-AL
Mg3
H125
H165
220
255
170
225
9
4
≤ 0,40 ≤ 0,40 ≤ 0,10 ≤ 0,50 2,60
÷
3,60
≤ 0,30 ≤ 0,20 ≤ 0,15 Mn+Cr
0,10
÷
0,60
EN
AW-5083
EN AW AL
Mg4,5 Mn0,7
H185 420 380 4 ≤ 0,40 ≤ 0,40 ≤ 0,10 0,40
÷
1,00
4,00
÷
4,90
0,05
÷
0,25
≤ 0,25 ≤ 0,15
EN
AW-5086
EN AW-AL
Mg4
H125
H145
H165
H185
270
300
320
350
170
220
260
320
9
7
5
3
≤ 0,40 ≤ 0,50 ≤ 0,10 0,20
÷
0,70
3,50
÷
4,50
0,05
÷
0,25
≤ 0,25 ≤ 0,15
EN
AW-7075
EN AW-AL
Zn5,5 MgCu
0 190 100 15 ≤ 0,40 ≤ 0,50 1,20
÷
2,00
≤ 0,30 2,10
÷
2,90
0,18
÷
0,28
5,10
÷
6,10
≤ 0,20

Allu’s production range is not restricted to the above-mentioned alloys, others are available to suit customers’ requirements.
For example we can recommend an alloy specially cast for us using recycled aluminium, which has mechanical properties – and therefore workability – almost identical to those of the alloy 5049.

CHARACTERISTICS AND APPLICATIONS
Alloys Characteristics Applications
1050A
1070A
1100
1200
Commercially pure aluminium, excellent corrosion resistance, good workability in the annealed condition. Chemical industry – food industry – aerosol – heat exchangers – lithographic – strip-decorative panels – kitchenware – fine sheet – automotive industry.
1050A / 1070A
1350A / 1370A
Good electrical conductivity in the annealed condition. Eletrical transformers.
3003
3103
3105
Manganese alloys, good corrosion resistence, good workability, mechanical properties higher than those of pure aluminium. Heat exchangers – kitchenware – car radiators – false ceiling systems – decorative panels – nuts and bolts signposts – chemical industry – automotive industry.
3005 Magnesium – manganese alloy, good corrosion resistance, good workability, mechanical properties higher than those of pure aluminium. Furniture – false ceiling systems – aerials – rolling shutters automotive industry.
5005 Magnesium alloy, mechanical properties higher than those of pure aluminium. Furniture – false ceiling systems – panel surfacing and linings – automotive industry.
5049
5052
5083
5086
5754
Magnesium alloys, excellent workability in the annealed condition but they work harden very quickly in cold manipulation. Suitable for welding and with excellent corrosion resistance, even in sea air. Chemical industry – food industry – carpentry – structural metal work – insulation – mouldings – land and sea transport seam welded tubes – venetian blinds – pressure vessels automotive industry.
5182 Magnesium alloy, suitable for welding, corrosion resistance high mechanical properties. Automotive industry
VALUATION METHODS FOR STRIPS IN ALUMINIUM ALLOYS
Alloy Temper Resistence to
corrosion
Aptitude for
surface treatements
Moulding Welding
Normal atmospheres Marine atmospheres Tension corrosion Aptitude for
brightness
Protective
anodizing
Decorative
anodizing
Cold bending Drawing Tool manipulation In gas Per resistence
1002 O O B O B O B O O I B B
1050A H24 O B O O O B B B S B B
  H18 O B O O O B S I S B B
3103 O O B O B O B O O I O O
  H24 O B O O O B B B S O O
  H18 O B O O O B S I S O O
5005 O B B O S B B O O I B B
  H34 B B O B B B B B S B B
  H36 B B O O B B S S S B B
  H18 B B O O B B S S S B B
5052 O O O O S B B B B I O O
  H34 O O O B B B S S S O O
  H18 O O O O B B I I B O O
5754 O O O O S B B B B S O O
  H34 O O O B B B S S S O O
  H36 O O O O B B S S B O O
5154B O O O O B B B B B S B B
  H34 O O O B B B S S B B B
  H36 O O O B B B I I B B B
5083 O B B B   B   B BB
6082 O B B O B O B O O S B B
  T4 O B B O O O B S B B* B*
  T6 O B O O O O S I O B* B*
7020 T6 S S S O B S S I B O** O**
7075 O I I I B S S I I B B** B**
  T6 I I I S S S I I B B** B**
O = Excellent S = Good enough * With mechanical properties decreasing. * * With partial recovery of mechanical properties.
B = Good I = Not good enough
HALF OVALS HALF OVALS Allu's
External
dimensions
Thickness (mm)
0,7 0,8 0,9 1,0 1,1 1,2 1,3 1,4 1,5 1,6 1,7 1,75 1,8 1,9 2,0
A x B (mm) Weight (g/ml)
21,7 x 19 132 151 169 187 204 222 239 257 274 290 307 315 324 340 356
50 x 25 257 293 329 365 400 436 471 506 541 575 610 627 644 678 713
Weights (g/m) are calculated assuming specific gravity to be equal to 2.7 and are indicative only.
OVALS OVALS Allu's
External
dimensions
Thickness (mm)
0,7 0,8 0,9 1,0 1,1 1,2 1,3 1,4 1,5 1,6 1,7 1,75 1,8 1,9 2,0
A x B (mm) Weight (g/ml)
18,4 x 9 85 96 108 119 130 140 151 162 172 182 192 197 202 211 221
20 x 15 103 117 131 144 158 171 184 197 210 223 235 241 247 259 271
23 x 14 121 137 153 170 186 202 217 233 248 263 278 286 293 308 322
27,5 x 14,7 132 151 169 187 204 222 239 257 274 290 307 315 324 340 356
30 x 15 144 164 184 204 223 242 261 280 299 318 336 345 354 372 390
30,2 x 17,2 150 171 192 212 232 252 272 292 312 331 350 360 369 388 407
33 x 20 162 185 207 229 251 273 294 316 337 358 379 390 400 421 441
35 x 20 174 198 222 246 270 293 316 340 363 385 408 419 431 453 475
36 x 18 174 198 222 246 270 293 316 340 363 385 408 419 431 453 475
40 x 12,1 174 198 222 246 270 293 316 340 363 385 408 419 431 453 475
40 x 20 192 219 245 271 298 324 350 375 401 426 451 464 476 501 526
50 x 10 210 239 268 297 326 354 383 411 439 467 495 508 522 550 577
45 x 25 221 252 283 314 344 375 405 435 464 494 523 538 553 582 611
48 x 19,8 221 252 283 314 344 375 405 435 464 494 523 538 553 582 611
54 x 10,15 221 252 283 314 344 375 405 435 464 494 523 538 553 582 611
48 x 25 233 266 298 331 363 395 427 458 490 521 552 568 583 614 645
Weights (g/m) are calculated assuming specific gravity to be equal to 2.7 and are indicative only.
ELLIPTICALS ELLIPTICALS Allu's
External
dimensions
Thickness (mm)
0,6 0,7 0,8 0,9 1 1,2 1,5 1,8 2,0 2,5
A x B (mm) Weight (g/ml)
26 x 18 126 144 161 178 212 261 308 339 414
28 x 20 144 164 184 204 242 299 354 390 477
33 x 26 174 198 222 246 293 363 431 475 583
37 x 22,1 180 205 230 254 303 375 446 492 604
40 x 20 186 212 237 263 314 388 461 509 626
40 x 26 198 225 253 280 334 414 492 543 668
Weights (g/m) are calculated assuming specific gravity to be equal to 2.7 and are indicative only.
SQUARES SQUARES Allu's
External
dimensions
Thickness (mm)
0,7 0,8 0,9 1,0 1,1 1,2 1,3 1,4 1,5 1,6 1,7 1,75 1,8 1,9 2,0
A x B (mm) r (mm) Weight (g/ml)
10 x 10 r. 1,5 67 76 85 93 102 110 118 126 134
12 x 12 r. 1 85 96 108 119 130 140 151 162 172
12,3 x 12,3 r. 1,5 85 96 108 119 130 140 151 162 172
14 x 14 r. 1,5 103 117 131 144 158 171 184 197 210 223 235 241 247 259 271
15 x 15 r. 1,5 109 124 138 153 167 181 195 209 223 236 249 256 263 276 288
16 x 16 r. 2,5 115 130 146 161 176 191 206 221 235 250 264 271 278 292 305
16,5 x 16,5 r. 1,5 121 137 153 170 186 202 217 233 248 263 278 286 293 308 322
18 x 18 r. 2 126 144 161 178 195 212 228 245 261 277 293 301 308 324 339
20 x 20 r. 1,5 144 164 184 204 223 242 261 280 299 318 336 345 354 372 390
22 x 22 r. 2,5 162 185 207 229 251 273 294 316 337 358 379 390 400 421 441
25 x 25 r. 3,5 174 198 222 246 270 293 316 340 363 385 408 419 431 453 475
30 x 30 r. 3   246 276 305 335 364 394 423 452 480 509 523 537 566 594
30 x 30 r. 4   239 268 297 326 354 383 411 439 467 495 508 522 550 577
40 x 40 r. 2   416 456 497 537 577 617 657 696 716 736 775 814
Weights (g/m) are calculated assuming specific gravity to be equal to 2.7 and are indicative only.
RECTANGULARS RECTANGULARS Allu's
External
dimensions
Thickness (mm)
0,7 0,8 0,9 1,0 1,1 1,2 1,24 1,3 1,4 1,5 1,6 1,7 1,75 1,8 1,9 2,0
A x B (mm) r (mm) Weight (g/ml)
15 x 10 r. 2 85 96 108 119 130 140 145 151 162 172
18 x 12 r. 1,5 109 124 138 153 167 181 187 195 209 223 236 249 256 263 276 288
18,3 x 12,3 r. 1,5 109 124 138 153 167 181 187 195 209 223 236 249 256 263 276 288
20 x 10 r. 1,5 109 124 138 153 167 181 187 195 209 223 236 249 256 263 276 288
20 x 15 r. 1,5 126 144 161 178 195 212 218 228 245 261 277 293 301 308 324 339
25 x 10 r. 2 126 144 161 178 195 212 218 228 245 261 277 293 301 308 324 339
25 x 12 r. 1,5 132 151 169 187 204 222 229 239 257 274 290 307 315 324 340 356
25 x 15 r. 1,5 144 164 184 204 223 242 250 261 280 299 318 336 345 354 372 390
24 x 18 r. 2,5 147 167 187 207 227 246 254 266 285 304 323 342 351 360 379 397
29 x 18 r. 3 162 185 207 229 251 273 281 294 316 337 358 379 390 400 421 441
32 x 15 r. 4 162 185 207 229 251 273 281 294 316 337 358 379 390 400 421 441
30 x 15 r. 1,5 162 185 207 229 251 273 281 294 316 337 358 379 390 400 421 441
30 x 20 r. 3,5 174 198 222 246 270 293 302 316 340 363 385 408 419 431 453 475
30 x 22,57 r. 6 174 198 222 246 270 293 302 316 340 363 385 408 419 431 453 475
33 x 20 r. 4,5   205 230 254 279 303 313 328 352 375 399 423 434 446 469 492
36 x 18 r. 4,5   212 237 263 288 314 324 339 363 388 413 437 449 461 485 509
33 x 20 r. 3,5   212 237 263 288 314 324 339 363 388 413 437 449 461 485 509
33 x 20 r. 3   219 245 271 298 324 334 350 375 401 426 451 464 476 501 526
33 x 20 r. 2   225 253 280 307 334 345 361 387 414 440 466 479 492 517 543
35 x 20 r. 3,5   219 245 271 298 324 334 350 375 401 426 451 464 476 501 526
35 x 20 r. 2   225 253 280 307 334 345 361 387 414 440 466 479 492 517 543
35 x 24 r. 4   239 268 297 326 354 366 383 411 439 467 495 508 522 550 577
40 x 20 r. 4   239 268 297 326 354 366 383 411 439 467 495 508 522 550 577
40 x 20 r. 3   246 276 305 335 364 376 394 423 452 480 509 523 537 566 594
40 x 22 r. 4,5   246 276 305 335 364 376 394 423 452 480 509 523 537 566 594
40 x 22,5 r. 6   246 276 305 335 364 376 394 423 452 480 509 523 537 566 594
40 x 25 r. 3   266 298 331 363 395 408 427 458 490 521 552 568 583 614 645
40 x 30 r. 3   286 321 356 391 425 439 460 494 528 562 596 612 629 662 696
43 x 20 r. 4,5   252 283 314 344 375 387 405 435 464 494 523 538 553 582 611
43 x 20 r. 3   266 298 331 363 395 408 427 458 490 521 552 568 583 614 645
45 x 20 r. 3   266 298 331 363 395 408 427 458 490 521 552 568 583 614 645
45 x 22 r. 2,5   280 314 348 382 415 429 449 482 515 548 581 597 614 646 679
45 x 30 r. 4,5   300 337 373 410 446 460 482 518 553 589 624 642 660 695 729
46 x 20 r. 3,5   266 298 331 363 395 408 427 458 490 521 552 568 583 614 645
46 x 22 r. 3   286 321 356 391 425 439 460 494 528 562 596 612 629 662 696
46 x 22 r. 6,5   266 298 331 363 395 408 427 458 490 521 552 568 583 614 645
47,6 x 21,6 r. 5     314 348 382 415 429 449 482 515 548 581 597 614 646 679
50 x 20 r. 3,5     321 356 391 425 439 460 494 528 562 596 612 629 662 696
50 x 20 r. 5     314 348 382 415 429 449 482 515 548 581 597 614 646 679
50 x 22 r. 2,5   373 410 446 460 482 518 553 589 624 642 660 695 729
50 x 25 r. 3   382 419 456 471 493 530 566 603 639 657 675 711 746
50,3 x 20,5 r. 4   356 391 425 439 460 494 528 562 596 612 629 662 696
50 x 30 r. 2   416 456 497 513 537 577 617 657 696 716 736 775 814
56 x 20 r. 2,5   399 438 476 492 515 553 592 630 668 687 705 743 780
58 x 25 r. 2,5   433 475 517 534 559 601 643 684 725 746 766 807 848
60 x 20 r. 2   416 456 497 513 537 577 617 657 696 716 736 775 814
60 x 24 r. 5   424 466 507 523 548 589 630 670 711 731 751 791 831
60 x 25 r. 3,5   441 484 527 544 570 613 655 698 740 761 782 824 865
60 x 30 r. 4,5   458 503 548 565 592 637 681 725 769 790 812 856 899
61,5 x 20 r. 4   416 456 497 513 537 577 617 657 696 716 736 775 814
61,7 x 24,7 r. 4   441 484 527 544 570 613 655 698 740 761 782 824 865
64 x 25 r. 3,5   548 565 592 637 681 725 769 790 812 856 899
64 x 25 r. 2,5   558 576 603 648 693 738 783 805 828 872 916
66 x 22 r. 2,5   548 565 592 637 681 725 769 790 812 856 899
67,7 x 24,7 r. 4   568 586 614 660 706 752 797 820 843 888 933
71,5 x 20 r. 2,5   568 586 614 660 706 752 797 820 843 888 933
73 x 25 r. 4,5   599 618 647 696 744 793 841 865 889 936 984
77 x 25 r. 3,5   629 650 680 732 782 833 884 909 934 985 1035
82 x 20 r. 4   629 650 680 732 782 833 884 909 934 985 1035
84 x 25 r. 2,5   680 702 736 791 846 901 956 983 1011 1065 1120
Weights (g/m) are calculated assuming specific gravity to be equal to 2.7 and are indicative only.
Rounds ROUNDS Allu's
External
dimensions
Thickness (mm)
0,6 0,7 0,8 0,9 1 1,1 1,2 1,3 1,4 1,5 1,6 1,7 1,75 1,8 1,9 2,0
D (mm) Weight (g/ml)
6 27 31
8 38 43 49 54 59
10 48 55 62 69 76
12 58 67 76 85 93 102 110 118 126 134
12,7 62 71 81 90 99 108 117 126 134 143
13 63 73 83 92 102 111 120 129 138 146
14 68 79 90 100 110 120 130 140 150 159
15 73 85 96 108 119 130 140 151 162 172
16 78 91 103 115 127 139 151 162 173 184 195 206 212 217 227 238
17 83 97 110 123 136 148 161 173 185 197 209 221 226 232 243 254
17,3 85 99 112 125 138 151 164 176 189 201 213 225 231 237 248 260
18 89 103 117 131 144 158 171 184 197 210 223 235 241 247 259 271
19 94 109 124 138 153 167 181 195 209 223 236 249 256 263 276 288
19,6 97 112 128 143 158 173 187 202 216 230 244 258 265 272 285 299
20 99 115 130 146 161 176 191 206 221 235 250 264 271 278 292 305
21 104 121 137 153 170 186 202 217 233 248 263 278 286 293 308 322
21,25 105 122 139 155 172 188 204 220 236 251 267 282 289 297 312 327
22 109 126 144 161 178 195 212 228 245 261 277 293 301 308 324 339
22,4 111 129 147 164 182 199 216 233 249 266 282 298 307 315 330 346
22,5 111 129 147 165 182 200 217 234 251 267 284 300 308 316 332 348
23 114 132 151 169 187 204 222 239 257 274 290 307 315 324 340 356
23,5 117 135 154 173 191 209 227 245 262 280 297 314 323 331 348 365
24 119 238 157 176 195 214 232 250 268 286 304 322 330 339 356 373
24,7 123 143 162 182 201 220 239 258 277 295 314 332 341 350 367 385
25 124 144 164 184 204 223 242 261 280 299 318 336 345 354 372 390
25,4 147 167 187 207 227 246 266 285 304 323 342 351 360 379 397
26 150 171 192 212 232 252 272 292 312 331 350 360 369 388 407
27 156 178 199 221 242 263 283 304 324 345 365 375 385 405 424
28 162 185 207 229 251 273 294 316 337 358 379 390 400 421 441
30 174 198 222 246 270 293 316 340 363 385 408 419 431 453 475
31 180 205 230 254 279 303 328 352 375 399 423 434 446 469 492
31,65 158 184 209 235 260 285 310 335 359 384 408 432 444 456 479 503
32 212 237 263 288 314 339 363 388 413 437 449 461 485 509
33 219 245 271 298 324 350 375 401 426 451 464 476 501 526
33,55 222 249 276 303 329 356 382 408 434 459 472 485 510 535
34 225 253 280 307 334 361 387 414 440 466 479 492 517 543
35 232 260 288 316 344 372 399 426 453 480 494 507 533 560
35,5 235 264 293 321 349 377 405 433 460 487 501 515 542 568
36 239 268 297 326 354 383 411 439 467 495 508 522 550 577
37,7 250 281 311 341 372 401 431 461 490 519 534 548 577 606
38 252 283 314 344 375 405 435 464 494 523 538 553 582 611
40 266 298 331 363 395 427 458 490 521 552 568 583 614 645
42 314 348 382 415 449 482 515 548 581 597 614 646 679
44 365 400 436 471 506 541 575 610 627 644 678 713
45 373 410 446 482 518 553 589 624 642 660 695 729
48 399 438 476 515 553 592 630 668 687 705 743 780
50 416 456 497 537 577 617 657 696 716 736 775 814
50,8 422 464 505 546 587 627 668 708 728 748 788 828
52 517 559 601 643 684 725 746 766 807 848
55 548 592 637 681 725 769 790 812 856 899
56 558 603 648 693 738 783 805 828 872 916
57 568 614 660 706 752 797 820 843 888 933
60 599 647 696 744 793 841 865 889 936 984
64 639 691 743 795 847 898 924 950 1001 1052
68 680 736 791 846 901 956 983 1011 1065 1120
70 700 758 815 872 928 985 1013 1041 1098 1154
72 721 780 838 897 955 1014 1043 1072 1130 1188
80 537 604 670 736 802 868 933 999 1064 1129 1162 1194 1259 1323
Weights (g/m) are calculated assuming specific gravity to be equal to 2.7 and are indicative only.
TOLERANCES (EN 1592-3/4)
a. Dimensions
The dimensions and the tolerances are not valid for the first 100 mm of both tube-ends

Circular tubes

Dimension tolerance
8 < D ≤ 15 ± 0,10 mm Including ovality
15 < D ≤ 40 ± 0,12 mm
40 < D ≤ 60 ± 0,15 mm
60 < D ≤ 80 ± 0,20 mm

Shaped tubes

Dimension tolerance
B o H ≤ 15 = ± 0,08 mm
15 < B o H ≤ 30 ± 0,10 mm
30 < B o H ≤ 50 ± 0,12 mm
50 < B o H ≤ 70 ± 0,15 mm
70 < B o H ± 0,20 mm

Flatness tolerance

B o H ≤ 15 y max = ± 0,05 mm
15 < B o H ≤ 30 ± 0,10 mm
30 < B o H ≤ 50 ± 0,20 mm
50 < B o H ≤ 70 ± 0,30 mm
70 < B o H ± 0,40 mm
Key: ①, ② measuring-point s
b. Thickness
0,5 ≤ t ≤ 1,0 ± 0,05 mm
1,0 < t ≤ 2,5 ± 0,08 mm
c. Length

Mill lenght

4000 < L < 8000 – 0 + 50 mm

Cut lenght

L < 1000 ± 1,0 mm
1000 ≤ L < 3000 ± 1,5 mm
3000 ≤ L < 7000 ± 2,0 mm
7000 ≤ L ± 3,0 mm
d. Straightness
L ≤ 1000 F max = 1,6 mm
L > 1000 F max <= 1,6 mm x L
SPECIAL PROFILES SPECIAL PROFILES Allu's

2
Profilo speciale 2

4
Profilo speciale 4

5
Profilo speciale 5

6
Profilo speciale 6


8
Profilo speciale 8

9
Profilo speciale 9

12
Profilo speciale 12

13
Profilo speciale 13


15
Profilo speciale 15

17
Profilo speciale 17

18
Profilo speciale 18

21
Profilo speciale 21


22
Profilo speciale 22

23
Profilo speciale 23

24
Profilo speciale 24

26
Profilo speciale 26


27
Profilo speciale 27

28
Profilo speciale 28

31
Profilo speciale 31

32
Profilo speciale 32


33
Profilo speciale 33

34
Profilo speciale 34

36
Profilo speciale 36

38
Profilo speciale 38


39
Profilo speciale 39

40
Profilo speciale 40

41
Profilo speciale 41

42
Profilo speciale 42


43
Profilo speciale 43

44
Profilo speciale 44

45
Profilo speciale 45

46
Profilo speciale 46


47
Profilo speciale 47

49
Profilo speciale 49

50
Profilo speciale 50

51
Profilo speciale 51


53
Profilo speciale 53

54
Profilo speciale 54

55
Profilo speciale 55

58
Profilo speciale 58


61
Profilo speciale 61

62
Profilo speciale 62

63
Profilo speciale 63

64
Profilo speciale 64


71
Profilo speciale 71

73
Profilo speciale 73

74
Profilo speciale 74

77
Profilo speciale 77
